BISTABLE secure pawl device 6.5T electrical

Auf Lager
SKU
46SO024E03000
Positioning at the bottom or at the top of the cabin arcade
Dimensions 458 x 200 x 102mm
52mm cleat exit
Very low consumption (200mA)
Bistable system
Low operating noise
Cleat position secured by pull-out contact

- Speed: 50 mm/s - Stroke 1s
- Operating temperature: 0° C to 50° C
- Protection: IP20
- Weight: 20Kg
- Lifetime: 400000 cycles
- Maximum static load: 6500Kg
- Axis force: 10N
- Motor: linear stepper
- Contact: 2x input and output position contacts 2A -230 VAC
- Operating voltage: 24VDC
- Number of fixings: 8 points Ø17 mm

This product is not a cushioned anti-drift cleat, but a safety or loading cleat (CF standard).
Weitere Informationen
Hersteller Sodimas
Tiefe 455 MM
Breite 200 MM
Höhe 102 MM
Netto-Gewicht 19,3 KG
Brutto-Gewicht 19,3 KG
